INTRODUCING

KONMOS TECHNOLOGY

INVERTER

The KONMOS motor and inverter are an system featuring high-RPM permanent magnet electric motors, power-dense electronic inverters, and advanced controls that enable electric vehicles to meet the highest standards for efficiency, reliability, and performance. Designed according to AIS 038 functional safety standards, these systems are efficient turnkey solutions optimized for high speed two wheeler and three wheeler application

System Features

  • Multiple driving mode
  • Efficient Algorithm
  • Programmable Current Limit , Torque control, Speed control
  • Compact Size
  • Thermal Optimized Design
  • Multiple Protections
  • High efficiency more than 96%
  • IP 65waterproof protection
  • Operating temperature upto 65 degree
  • Can communication
  • Aluminum Body with better heat dissipation

Applications

KONMOS series is an efficient turnkey solution created expressly for a range of electric and hybrid applications, with emphasis on high speed two wheelers, three wheelers, Load carriers such as:

  • Two Wheelers
  • Three Wheelers
  • Load Carriers
  • Passenger Vehicle
  • Commercial Vehicle
KONMOS7206 KONMOS4802 KONMOS6002
Rated Power 6 kw 2 kw 2 kw
peak Power 11 kw 4 kw 4 kw
Nominal Voltage 72 V 48 V 60 V
Max Voltage 84 VDC 55 VDC 70 VDC
Efficiency 96% 96% 96%
RPM 4200 3000 3000
Max RPM 6000 4500 4500
Rated Torque 13.6 Nm 6.3 Nm 6.3 Nm
Peak Torque 28 Nm 12.6 Nm 12.6 Nm
Ingress Level IP65 IP65 IP65
Cooling Forced Air Forced Air Forced Air
Weight 4 kg 1.5 kg 1.5 kg
